Fronius Magicwave 230i AC DC Tig Welder 120/220 Volt

49,0410,0031 (READY TO WELD PACKAGE) Excellent for Tig Welding Aluminum

Magicwave 230i AC / DC Stick/Tig Ready 2 Weld Package with Case

This power source can optionally be supplied with a water-cooling system and is suitable for all welding applications apart from aluminium. Comes as a  multivoltage version, meaning they can be used anywhere in the world – even with different mains voltages.

Fronius Magicwave comes ready to weld almost any material out there, including Bronze, Aluminum, Nickel Chrome, Stainless and Carbon Steel.

Demo of this machine is available at any of our locations, or we can come out to your facility if it is within the GTA and Southern Ontario.

High open circuit voltage and ample power reserves improve HF ignition behaviour
2 kHz pulse welding as standard on all devices; the PulsPro function package can deliver a pulse frequency of up to 10 kHz
Saving and editing of up to 999 jobs using the Job function package

Features:

• AC / DC Power Source
• High Frequency Ignition
• 2 kHz pulse welding as standard on all devices
• Tig Welding Range 3-230 Amps
• Stick Electrode Range 10-190 Amps
• 100 foot Extension Cables Available (Upt o 300 feet from power source)

PERFORMANCE ON 120 VOLTS USING A 20 AMP CIRCUIT:

• Tig 35% 170 Amps / Stick 120 Amps
• Tig 60% 140 Amps / Stick 105 Amps
• Tig 100% 120 Amps / Stick 85 Amps

PERFORMANCE ON 240 VOLTS USING A 20 AMP CIRCUIT"

• Tig 35% 230 Amps / Stick 190 Amps
• Tig 60%  205 Amps / Stick 155 Amps
• Tig 100% 170 Amps / Stick 125 Amps

WEIGHTS AND SIZES:

• DIMENSIONS WITH HANDLE 22.0 / 8.3 / 14.5 in.
• WEIGHT  15.9 Kg / 35.1 lb

PACKAGE COMES COMPLETE WITH THE FOLLOWING:

4,075,219,631 Magicwave 230i Power Source MV/B

4,046,112 Wireless Foot Pedal (Blue Tooth)

4,051,305 Tig Hose Pack Multi Lock (power cable) THP 220i G ML/F/UD/13.12ft/LED

44,0350,4409 Tig Torch Body (Multi Lock) TTB 220P G ML/70°/L65

43,0004,0479 Ground Cable No.4 gauge (25mm²) 4m/13ft 60% Duty Cycle 250A Male Connector Dinse  35mm² with earth clamp

42,0441,0005 Gas Regulator (Flowmeter)

42,0001,3541 Gas Adapter (Used to convert to B Size Hose Fittings)

44,0350,0781 Tig Consumable Kit (Fits torch body's TTB260A / TTG2200A / TTW5000A

42,0510,0283 Tool Case Caddy with Rear Wheels Model 120
